M1614-MP2 Computar

打印
Share

  • 產品詳情
  • 產品參數
  • 資料下載
Dimensions



f=16mm  F1.4

ｆor 2/3 type Megapixel  Cameras

C-Mount

Model No.

M1614-MP2

Effective

Lens Aperture

Front

φ18.5mm

Focal Length

16mm

Rear

φ13.2mm

Max. Aperture Ratio

1:1.4

Distortion

2/3type

-0.1%(y=5.5)

Max. Image Format

8.8mm x 6.6mm(φ11mm)

1/2type

-0.3%(y=4.0)

Operation Range

Iris

F1.4‐ F16C

Back Focal Length

13.1mm

Focus

0.3m ‐ Inf.

Flange Back Length

17.526mm

Control

Iris

Manual

Mount

C-Mount

Focus

Manual

Filter Size

M30.5 P=0.5mm

Object Dimension  at M.O.D

2/3 type

17.2cm x 12.9cm

Dimensions

φ33.5mm x  28.2mm

1/2 type

12.5cm x 9.3cm

Weight

60g

Angle of View


D

2/3 type

38.0°

1/2 type

28.2°



H

30.8°

22.7°


V

23.4°

17.1°


Operating Temperature

-10℃ ‐ +50℃



M.O.D : Minimum Object Distance
